ABS pipe extrusion line
| Price: | 30000.0~300000.0 USD |
| Payment Terms: | T/T,L/C,WU |
| Place of Origin: | Shandong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
1. High quality machine due to our new design and best accessories, parts and manufacturing.
2. High stability and reliability
3. lifetime servic
ABS pipe extrusion line:
FEATURE AND FUNCTION of ABS pipe extrusion line:
The screw of the extruder is equipped with barrier unit and mixing structure, and the barrel owns new style grooves. All of these offer good plastification and mixing effect. Special design of basket die head for HDPE(PP,ABS) large diameter pipe with thick wall off lower melting temperature, good mixing, lower pressure and stable production.
Special design for sizing and cooling system by using film and water ring to cool HDPE (PP, ABS) materials, can fit for the requirement of HDPE(PP,ABS). And the design can ensure the stability of diameter and roundness when producing pipes with thick wall.
Special designed vacuum sizing tank can ensure the stability of size and roundness. Speed controllers are used in extruder, haul-off to offer stability and precision.
The whole ABS pipe extrusion line adopts PLC control system and large liquid crystal screen, which makes the operation very convenient. The line can also be equipped with special extruder for making pipes with mark lines.
The screw of the extruder is equipped with barrier unit and mixing structure, and the barrel owns new style grooves. All of these offer good plastification and mixing effect. Special design of basket die head for HDPE(PP,ABS) large diameter pipe with thick wall off lower melting temperature, good mixing, lower pressure and stable production.
Special design for sizing and cooling system by using film and water ring to cool HDPE (PP, ABS) materials, can fit for the requirement of HDPE(PP,ABS). And the design can ensure the stability of diameter and roundness when producing pipes with thick wall.
Special designed vacuum sizing tank can ensure the stability of size and roundness. Speed controllers are used in extruder, haul-off to offer stability and precision.
The whole ABS pipe extrusion line adopts PLC control system and large liquid crystal screen, which makes the operation very convenient. The line can also be equipped with special extruder for making pipes with mark lines.
Main Technical Parameters of ABS pipe extrusion line: | ||||
OD RANGE | MATCHED EXTRUDER | MAX OUTPUT | TOTAL INSTALLED POWER | |
SY-110 | 20-63 | SY -SJ60/33 SY -SJ25/25 | 120-220 | 130 |
SY -160 | 50-160 | SY -SJ60/33 SY -SJ25/25 | 120-220 | 130 |
SY -250 | 110-250 | SY -SJ75/33 SY -SJ25/25 | 280-350 | 280 |
SY -450 | 160-450 | SY -SJ90/33 SY -SJ25/25 | 350-450 | 400 |
SY -630 | 315-630 | SY -SJ120/33 SY -SJ30/30 | 550-980 | 550 |
SY -800 | 400-800 | SY -SJ150/33 SY -SJ30/30 | 800-1400 | 750 |
SY -1600 | 800-1600 | SY -SJ150/33 SY -SJ30/30 | 800-1400 | 1200 |
